Pwmp gêr hydrolig jihostroj qhd2
Cylchdro deuol bi - 4h brite: dadleoli: {35-133 pwysau gweithio (bar): 250-270 cyflymder (rpm): {2000-2500 pwmp gêr cylchdroi dwbl iso 4h: dadleoli: 82 pwysau gweithio (bar): 225 Cyflymder (rpm): bar porthladdoedd: 2000 c 110: Cyflymder 250 (rpm): 2250-2500
Qhd 2 43, qhd 2 51, qhd 2 56, qhd 2 61, qhd 2 71, qhd { {5}}, qhd 2 90, qhd 2 100, qhd 2 110, qhd 2 125, qhd {2 150
|
Enwol Maint Baramedrau |
Sym. |
Unit |
Qhd2 43 |
Qhd2 51 |
Qhd2 56 |
Qhd2 61 |
Qhd2 71 |
QHD2 82 |
|
|
Dadleoliad gwirioneddol |
VG |
[cm3] |
43.57 |
51.81 |
56.52 |
61.23 |
71.83 |
82.43 |
|
|
Cyflymder cylchdroi |
enwol |
nn |
[min -1] |
1500 |
1500 |
1500 |
1500 |
1500 |
1500 |
|
isafswm |
nmin |
[min -1] |
400 |
400 |
400 |
400 |
400 |
400 |
|
|
uchafswm |
nmax |
[min -1] |
3200 |
3200 |
3200 |
3200 |
3200 |
3000 |
|
|
Pwysau yn y Gilfach* |
isafswm |
P1min |
[Bar] |
-0,3 |
-0,3 |
-0,3 |
-0,3 |
-0,3 |
-0,3 |
|
uchafswm |
p1max |
[Bar] |
0,5 |
0,5 |
0,5 |
0,5 |
0,5 |
0,5 |
|
|
Pwysau yn allfa ** |
Max. pharhaus |
p2n |
[Bar] |
280 |
280 |
280 |
270 |
260 |
260 |
|
uchafswm |
p2max |
[Bar] |
300 |
300 |
300 |
290 |
280 |
280 |
|
|
nghynnalau |
p3 |
[Bar] |
310 |
310 |
310 |
300 |
290 |
290 |
|
|
Cyfradd llif enwol (min.) Yn NN a P2N |
QN |
[dm3 .min -1] |
60.4 |
69.9 |
76.3 |
82.7 |
99.1 |
116.2 |
|
|
Uchafswm cyfradd llif yn nmax a p2max |
Qmax |
[dm3 .min -1] |
136.6 |
162.5 |
177.2 |
192.0 |
225.3 |
242.3 |
|
|
Pwer Mewnbwn Enwol (Max.) Yn NN a P2N |
Pn |
[KW] |
36.1 |
44.8 |
48.8 |
51.0 |
56.4 |
63.3 |
|
|
Uchafswm pŵer mewnbwn yn nmax a p2max |
Pmax |
[KW] |
79.0 |
94.0 |
102.5 |
107.4 |
121.6 |
130.8 |
|
|
Mhwysedd |
m |
[kg] |
– |
– |
– |
– |
– |
– |
|
|
Enwol Maint Baramedrau |
Sym. |
Unit |
QHD2 90 |
QHD2 100 |
QHD2 110 |
QHD2 125 |
QHD2 150 |
|
|
Dadleoliad gwirioneddol |
VG |
[cm3] |
90.67 |
100.09 |
110.69 |
125.99 |
150.72 |
|
|
Cyflymder cylchdroi |
enwol |
nn |
[min -1] |
1500 |
1500 |
1500 |
1500 |
1500 |
|
isafswm |
nmin |
[min -1] |
400 |
350 |
350 |
250 |
250 |
|
|
uchafswm |
nmax |
[min -1] |
2800 |
2700 |
2600 |
2400 |
2000 |
|
|
Pwysau yn y Gilfach* |
isafswm |
P1min |
[Bar] |
-0.3 |
-0.3 |
-0.3 |
-0.3 |
-0.3 |
|
uchafswm |
p1max |
[Bar] |
0.5 |
0.5 |
0.5 |
0.5 |
0.5 |
|
|
Pwysau yn allfa ** |
Max. pharhaus |
p2n |
[Bar] |
240 |
230 |
210 |
190 |
170 |
|
uchafswm |
p2max |
[Bar] |
260 |
250 |
230 |
210 |
190 |
|
|
nghynnalau |
p3 |
[Bar] |
270 |
260 |
240 |
220 |
200 |
|
|
Cyfradd llif enwol (min.) Yn NN a P2N |
QN |
[dm3 .min -1] |
127.8 |
141.1 |
156.1 |
177.6 |
212.5 |
|
|
Uchafswm cyfradd llif yn nmax a p2max |
Qmax |
[dm3 .min -1] |
248.8 |
264.8 |
282.0 |
296.3 |
295.4 |
|
|
Pwer Mewnbwn Enwol (Max.) Yn NN a P2N |
Pn |
[KW] |
64.3 |
68.0 |
68.7 |
70.7 |
75.7 |
|
|
Uchafswm pŵer mewnbwn yn nmax a p2max |
Pmax |
[KW] |
124.7 |
127.7 |
125.1 |
120.0 |
108.2 |
|
|
Mhwysedd |
m |
[kg] |
– |
– |
– |
– |
– |
|
